Q345C grade size 4*1219*2438mm Steel plate
Description:
Standard：GB/T 1591-2018
Grade：Q345B/Q355B, Q345C/Q355C, Q345D/Q355D
Deliver Condition：Hot rolling
| Grade | C | Si | Mn | P | S | Nb | V | Ti | Cr | Ni | Cu | N | Mo | Als |
| Q345B | ≤0.20 | ≤0.50 | ≤1.70 | ≤0.035 | ≤0.035 | ≤0.07 | ≤0.15 | ≤0.20 | ≤0.30 | ≤0.50 | ≤0.30 | ≤0.012 | ≤0.10 | / |
| Q345C | ≤0.20 | ≤0.50 | ≤1.70 | ≤0.035 | ≤0.030 | ≤0.07 | ≤0.15 | ≤0.20 | ≤0.30 | ≤0.50 | ≤0.30 | ≤0.012 | ≤0.10 | ≥0.015 |
| Q345D | ≤0.18 | ≤0.50 | ≤1.70 | ≤0.035 | ≤0.025 | ≤0.025 | ≤0.15 | ≤0.20 | ≤0.30 | ≤0.50 | ≤0.30 | ≤0.012 | ≤0.10 | ≥0.015 |
Mechanical Properties:
| Grade | Yeild Strength min Mpa | Tensile Strength | Elongation | Impact Test | |||
| T in mm | Mpa | ||||||
| ≤16 | ＞16 ≤30 | ＞30 | ℃ | Impact/J | |||
| ≥ | |||||||
| Q345B | 345 | 325 | 295 | 470-630 | ≥20 | 20 | 34 |
| Q345C | 345 | 325 | 295 | 470-630 | ≥21 | 0 | 34 |
| Q345D | 345 | 325 | 295 | 470-630 | ≥21 | -20 | 34 |
Q345C is a kind of low-alloy high-strength structural steel: (corresponding to the old grades before 88 years: 16Mn,
12MnV, 14MnNb, 16MnRe, 18Nb five grades merged) Q is the first letter of the Chinese pinyin of the Chinese
character “yield”, indicating the strength of yield 345 is the specific value of yield strength: 345MPa The C at
the back is the quality grade symbol of the steel of this strength level, generally divided into A, B, C, D, E and
other levels (the higher the level, the higher the level) Note: The five grades A, B, C, D, E do not correspond
to the previous five steel grades, but the quality grades. The main difference is that the requirements for impact
energy are different: Q345-A: Impact power is not required Q345-B: Requirements for impact energy at room
temperature Q345-C: requires 0℃ impact energy Q345-D: requires an impact energy of -20℃ Q345-E: requires
-40℃ impact energy It can be seen that the following steel grades can be used at low temperatures
